270193 Wicke Drive WHEEL PS 213/ 70-190/FL-S AS:6/160,5/142,1 D:6.5 mm + 3xM6 + 3×6,5 52356092

This Drive wheel has an outer diameter of 213 mm, a 142 mm centre bore, a 6-bolt mounting pattern on a 162 mm PCD

Pitch circle diameter 162.0 mm
Width of the wheel 70 mm
Wheel profile Smooth
Shaft diameter 142.00 mm
Number of bolt holes 6
Diameter of the bolt holes 6.50 mm
Material of the wheel Polyurethane
Colour of the wheel Brown
Durometer 92 A

Compatible Electric Pallet Truck Models

• Linde: MT15 (specifically the 1133-03 series).
• STILL: ECH 15 and ECH 15C.
• EP Equipment: EPT20-15ET2 and EP F4

MSA Part Number

• Linde / STILL OEM Part Number: 0009934064
• EP Equipment OEM Part Number: ZL1021000000
• Jungheinrich OEM Part Number 52356092

This wheel is finished in a 92 A brown polyurethane, it is designed to operate primarily on smooth indoor warehouse concrete floors. The high 92A rating prevents the wheel from compressing or “flat-spotting” when the pallet truck is left parked while carrying its maximum 1.2 to 1.5-tonne capacity.

Matching load rollers

For the same trucks

MSA Part number 271158

Jungheinrich Part Number 51371807

• Jungheinrich Ameise AM2200 series, AM22, and several of their compact electric pedestrian stackers.
• BT / Toyota: Frequently used on older and modern BT Lifter manual and semi-electric series (such as the LHM230 tandem setups).
• Noblelift & PT-Warehouse Series: Standard fitment for Noblelift economic pallet trucks and lift tables.

• 47 mm Chamber / 14 mm Depth: This matches the standard outer diameter profile of a 6204 deep-groove ball bearing.
• 63 mm Clamping Length: The overall clamping length (63.0 mm) is slightly wider than the wheel tread itself (60.0 mm), the hub slightly protrudes or uses an integrated step. This prevents the moving polyurethane tread from rubbing against the steel fork chassis of the truck.

Castor Wheel

MSA Part Number 271163

• EP Equipment: F4, F1, F2, F3, EPL154, EPL163, EPL185, EPL205Z, EPT20-15ET3, EPT20-ET, and the XP15 series.
• Big Joe: Compact electric pallet jacks built on the EP Equipment chassis platform.
• Heli Equipment: Specific lithium-powered light-duty walkie trucks. [1,

• EP Equipment Part Number: 1155-172101-00

• Jungheinrich Part Number 52540162
